MOORE #3 JIG BORER RETROFIT IN 2001 w/ANILAM 3200MK CNC
MOORE #3 JIG BORER RETROFIT IN 2001 w/ANILAM 3200MK CNC
** ANILAM 3200 MK 3-AXIS CNC CONTROL INSTALLED NEW IN 2001)
MODEl: B-18 S/N: B-1194 NEW: 1967
TABLE SIZE ............................... 11" X 24" TABLE
LONGITUDINAL TABLE TRAVEL ................ 18"
CROSS TABLE TRAVEL ....................... 11"
SPINDLE HOUSING TRAVEL ................... 12"
SPINDLE QUILL TRAVEL ..................... 5"
TABLE TOP TO SPINDLE, MIN. ............... 3- 7/8"
MAX. ............... 20- 13/16"
SPINDLE TO COLUMN WAYS ................... 10"
SPINDLE TO COLUMN BELOW WAYS ............. 13- 3/4"
BORING CAPACITY .......................... 5/32" TO 5"
INFINITELY VARIABLE SPINDLE SPEEDS ....... 60 TO 2,250 RPM
FEEDS PER REV. (3) .............. 0.000075", .0015" & .003"
APPROX. WEIGHT ........................... 4,000 LBS.
APPROX. DIMENSIONS ..................... 58" X 60" X 89"H
HARDENED, GROUND & LAPPED LEADSCREWS
TWO-SPEED MOTOR (1 H.P. & 2 H.P.)
MACHINE IS PRESENTLY WIRED FOR 3/60/440 VOLTS/5 AMP SERVICE
"ANILAM" 3200MK 3-AXIS CNC CONTROL INSTALLED IN 2001
Moore Collet w/ Albrecht 0-10mm Keyless Drill Chuck
Moore Collet w/Criterion #2 Boring Head
** SUPERB CONDITION & APPEARANCE (ORIGINAL PAINT) **
** INSPECT UNDER POWER IN OUR HARRISON, N.J. WAREHOUSE **
Machine Location: HARRISON, NJ
