Schwabe sr-300 die cutting press
SCHWABE MODEL SR-300 HYDRAULIC DIE CUTTING PRESS*
Capacity: 300 Ton
Stroke: 8" (Adjustable)
Open Height: 10" (Max.)
Closed Height: 2"
Slide Area: 64" L-R x 40" F-B
Bed Area: 64" L-R x 40" F-B
Adjustable Feed Speed
Programmable Feed Length
Flush Floor Design
Down Acting
EQUIPPED WITH:
Siemens PLC Control
68" Programmable Front Mounted Roller Feeder
Flatbelt Conveyor (120" x 68")
Automatic Lower Pad Shifter
Digital Die Height Read-out
Stroke Counter; Batch Counter
Hydraulic Power Unit
25 HP AC Main (Pump) Motor
Electrical Controls
Push Button Operation
Approximate Overall Dimensions: 110" L-R x 70" F-B x 85" H
Approximate Weight: 20,000 Lbs.(CONVEYOR: 130"X 88"X 63")
(HYRD.:66"X 43"X 37"H)
Serial Number: 43112 (New 1991)
P2 F.O.B. Elk Grove, IL - $ 99,500.00
* PRELIMINARY SPECIFICATIONS SUBJECT TO VERIFICATION
