Grundfos thru spindle high pressure coolant system
You are looking at Grundfos High Pressure Coolant System
* sum pump which is used to supply dirty coolant from your coolant tank to Grundfos unit which is equipped with two tanks dirty coolant storage 40 gallons and clean coolant storage 40 gallons.
* centrifugal cleaner with its own pump which works as filtering system and oil separator.
* high pressure up to 450 PSI Grundfos pump which supplies clean coolant to thru spindle coolant system.
* system generates enough coolant volume so you can separate it for thru spindle coolant and powerful showering system.
This system is made in mind for CAT50 horizontal milling centers with 24 hour duty usage and no maintenance , please direct all questions to ****@partscnc.com we have great technicians which can set it up for you onsite for $50.00 / hour including plumbing, electrical and control setup for any system and any configuration separate M codes FANUC, OKUMA, YASNAC etc. , don't hesitate to make an offer.
THANK YOU FOR LOOKING AT OUR LISTING.
40 Gallons Dirty and 40 Gallons Clean coolant
Main high pressure Grundfos pump and motor:
GRUNDFOS Model No. CRK2-180 A-W-A-AUUV
3 cubic meters per hour 3500 RPM H 177.9 m
10 HP dual voltage 208-240 / 460-480 Volts
Centrifugal Filter / Oil skimmer pump:
CENTRIFUGAL CLEANER MADE BY LEAP 50 liters a min TYPE CI-30
5 HP dual voltage 208-240 / 460-480 Volts
Centrifugal Groundfos 1.5 HP dual voltage 208-240 / 460-480 Volts
