2000KW diesel generator
Zero run hours, Unit is new surplus stock
2000EKW with Fan, 2876 HP, 1800 RPM, 60 HZ,
Separate Circuit After Cooler, 4 Turbocharger, Dry Manifold, Direct Injected,
Stand By Rated, 480 Volt, .8 Power Factor
Engine manufactured 12-20-2000, package model year of 2001
Enclosed in a sound attenuated, skid base enclosure
Features and Accessories for the unit includes:
Air cleaner, regular duty, with service indicators
Two turbochargers - center mounted
Two turbochargers - rear mounted
ADEM~ Electronic engine control
Blower fan, fan drive, and fan guard
Engine-jacket water coolant thermostats, full open temperature 198° F.
Jacket water pump, gear driven, centrifugal
Split core, two circuit, engine jacket water and after cooler water
After cooler water pump, gear driven, centrifugal
After cooler cooling pump circuit contains thermostat to keep after cooler water from falling below
Exhaust manifold, dry, dual 8 inches
Four turbo arrangement - center mounted
150 Gallon Double Wall Day Tank
Generator and Generator Attachments
Generator arrangement 144-1828
480V, 3 phase, 0.8 power factor, 4 Pole
EMCP II + control panel including:
NEMA 1, IP44 Dust Proof Enclosure
Auto start/stop control switch
Voltage adjustment potentiometer
Line to Line Volts, Line to Neutral Volts, Phase, Amps, Hz
eKW, KVa, kVAR, kWhr, % KW, PF
Shutdowns with indicating lights for:
Programmable Protective Relaying Functions
Over Current (phase and Total)
3 Spare indicating LED's (programmable)
Low/high coolant temperature alarm
High coolant temperature shutdown
Over crank and over speed shutdown
Crankcase breather, top mounted
Oil cooler (mounted on radiator)
Crankcase explosion relief valve
Dual 24 volt electric starting motors
Caterpillar group 4D batteries
LaMarche 1 pc. Model A46-20-24V-Al with 16E alarm package
Dual jacket water heater, kW total, 120-240V single phase, fixed thermostat 140 degree .
Custom manufactured by International Supply Company
Meets Dade County Florida, 2001, 110 MPH wind load requirements
Enclosure dimensions are 158.5†high, 144†wide, 474†long, 84,000 Lbs. weight
Discharge hood is 130†high, 88†wide, 144†long, 2500 Lbs. weight
The Following Accessories will Be Supplied loose for the unit.
Qty. 10 pc. PIN 822-K Seismic Vibration Isolators
Units have Zero hrs, they are set up for prime power. Please view all photos for information, we can supply fuel tanks if needed.
