Oz~atlas/craftsman lathe 3980,3981,3982,3983,3990,3991
"NOS. 3980, 3981, 3982, 3983, 3990, AND 3991
12" Atlas Backgeared Screw Cutting Lathe"
This is a reproduction, not a photocopy, of an original 12" Atlas Backgeared Screw Cutting Lathe for models 3980, 3981, 3982, 3983, 3990, and 3991. This was also sold under the Craftsman brand name. This manual contains information on setup, lubrication, maintenance, and controls as well as a complete parts list and exploded views and adjustments. This manual has a excellent description of removing the headstock spindle, removing the back gears, assembling the back gears, and resembling the headstock spindle. This manual also has a very excellent and very important description on adjusting the spindle and back gear, with Timken Bearings this is critical. Another nice thing about this manual is the electrical diagram at the end. Don't forget to check out my other items!
Horizontal Countershaft Lathe Mounting...................2
Underneath Drive Lathe Mounting.......................2&3
Leveling The Bed.....................................................3
Lubrication...............................................................3
Operations and Controls..........................................4
Selection of Threads and Feed.................................5
Setting Tool Bits.......................................................6
Threading Adjustments.............................................6
Headstock...............................................................7
Quick-Change Gear Box..........................................8
Saddle and Slides.....................................................9
Apron....................................................................10
Bed and Tailstock..................................................11
Tumbler Assembly..................................................12
Horizontal Countershaft Assembly..........................13
Guards Assembly...................................................14
Underneath Drive Assembly...................................15
Cabinet Assembly..................................................16
Removing Headstock Spindle.................................17
Removing Back Gear.............................................17
Spindle and Timken Bearing Adjustment.................18
Belt Adjustment.....................................................18
Lubrication Chart............................................19&20
Wiring Diagram......................................................21
I have collected this information for many years and have found the information they contain to be priceless in using and setting up the machines properly. I believe this manual will be a valuable resource of knowledge that will provide a lot of helpful information that is often hard to find. My manuals are not photocopies. I maintain a high standard of quality in my reproductions. Most of the manuals I reproduce look better than their originals. I have professionally digitally edited every page, and removed stains, wrinkles and handwriting. All of the manuals are printed on thick white paper to withstand shop wear and tear; they are then comb bound with heavy cover pages so they lie flat on the workbench.
Be sure to add me to your favorites list!
I am adding new manuals all the time.
PLEASE READ the return policy and COMPLETE description of the manual.
Because of the nature of this product, I do not accept any returns or exchanges
under any circumstances. If you have any questions, email me or send me a picture first. I
