% linseis upright recorder l-7005 n/r
Recorders - Modular, Vertical, 250mm, Linseis Series L7005
Series L7005 is in an upright, modular design for stacking if needed. Writing width is 250 mm; with a pull-out writing table for making notations on chart paper. The fixed settings control the sensitivity by use of a variable gain control that allows a maximum, full scale sensitivity of 0.4 mv. Available in 1 to 6 channels with 15 switchable measuring ranges from 1 mV to 50 volts, full-scale deflection. A variable span facility increases the overall sensitivity by a factor of up to 2.5 with a maximum chart speed of 100 cm/minute forward and reverse. The crystal-controlled stepping motor allows chart speeds of 1 cm/min. to 100 cm/hr.; chart speeds are: 1, 2, 5, 10, 20, 50, 100, 200, 500, 1000 cm/min or cm/hr. Time is within 0.35 seconds. Accuracy and linearity: ±0.35% and ±0.25%, respectively. With overload protection of ±60 volts. Rolled or Z-fold paper can be used without modification. Easy to use front-mounted controls. Modular units consist of three chassis: 2-, 4-, and 6-channel. Each chassis requires input modules and a pen servo unit for each channel (see below). For a 2-channel instrument, select a 2-channel chassis, plus two input modules; for a 3-channel instrument select a 4-channel chassis, plus three input modules; for a 4-channel instrument select a 4-channel chassis plus four input modules; for a 5-channel instrument, select a 6-channel chassis, plus five input modules; for a 6-channel instrument, select a 6-channel chassis, plus six input modules.
PLEASE NOTE THIS UNIT POWERS UP. THAT IS TH ONLY TESTING WE HAVE BEEN ABLE TO DO.
SO THE PRODUCT IS NOT GUARANTEED TO WORK HOWEVER IT IS GUARANTEED POWERUP....
This Item is Protected by a DOA guarantee
for tests completed, and conditions as described, above
